News
Category: Active Components
| Optoelectronics, Active Components, BECK Elektronik
5kW, 16 – 100V Surface Mount Transient Voltage Suppressor
Taiwan Semiconductor officially introduces its 5000 Watt High Power Surge Capability Uni-Directional TVS in DO-214AB (SMC) with reliable thermal performance up to TJMAX=175°C.
TSC’s 5.0 SMDJ series offer total 26 new Part Numbers with working stand-off voltages from 16V to 100V, excellent clamping capability from 26V to 162V.
Features:
- 5000 Watt peak pulse power capability at 10/1000µs…
| Active Components, BECK Elektronik
Low Capacitance ESD Protection
Taiwan Semiconductor introduces new Low Capacitance ESD Protection devices designed to protect high-speed data interfaces at 5V standoff voltage.
All parts meet at least IEC61000-4-2 (ESD) requirements of ±15kV (air), ±8kV (contact) and support surge resistance requirements for high-speed data lines like USB, HDMI, Display Port, SATA and DVI.
Parts include 4-channel ESD protection arrays in…
| Optoelectronics, Active Components, BECK Elektronik
Linear Constant Current Regulated LED Driver
The TSCR4xx are Constant Current Regulator (CCR) for linear LED driving.
The devices regulate with a preset 10mA nominal that can be adjusted with an external resistor up to 300mA (TSCR420CX6/TSCR421CX6), respectively a preset of 0.1mA (TSCR400CX6) and 20mA (TSCR402CX6) nominal that can be adjusted with an external resistor up to 65mA. They have been designed for driving LEDs in strings and will…
| Optoelectronics, Active Components, BECK Elektronik
ESD Capable Rectifier
A new family of electro-static discharge (ESD) capable rectifiers from Taiwan Semiconductor.
All TSDxx parts have a repetitive peak reverse voltage (VRRM) of 400 V and forward current ratings (IF(AV)) of 1 A to 3 A in package types SOD-123W, SMA, SMB and SMC packages. These parts are glass passivated and offer low forward voltage drop (VF), high surge current capability (IFSM) and high ESD…
| Active Components, BECK Elektronik
2.2 A, 400 V – 1000 V Surface Mount Bridge Rectifier
Taiwan Semiconductor is introducing bridge rectifiers in a small, low profile (height 1.5 mm) surface mount YBS package.
The first series of parts is YBS220xG with VRRM range from 400 V to 1000 V, and IF(AV) = 2.2 A. The TSC YBS package is compatible with Liteon MSBL and MCC TBS packages. The YBS series of bridge rectifiers offers performance suitable for power supply designs in the =65 W range…
| Optoelectronics, Active Components, BECK Elektronik
600V Super Junction 2nd Generation N-Channel MOSFETs
Taiwan Semiconductor has released a second generation of600 V super junction power MOSFETs.
- Faster, higher efficiency switching performance
- Improved figure of merit
- Faster recovery
The TSM60NBxxx family of 600 V N-channel power MOSFETs offer RDS(on)(max) ranging from 190 mO to 1.4 O.
The advanced and proprietary super-junction technology is specifically designed to resolve the efficiency…
| Active Components, BECK Elektronik
200 V Surface Mount Ultra Fast Rectifiers
A new family of 200 V glass passivated Ultra Fast Rectifiers ESxDV with junction chip, trr < 20 ns, and maximum average forward rectified current IF(AV) from 1 A to 3 A have been released.
All ESxDV are available as AEC-Q101 certified versions for automotive applications.
Features:
- Glass passivated junction chip
- Ultra fast recovery time for high efficiency (ES1DV)
- Super fast recovery time…
| Optoelectronics, Active Components, BECK Elektronik
1000 V High Voltage Planar N-Channel MOSFETs
Taiwan Semiconductor is introducing the TSMxN100CP family of 1000 V power MOSFETs produced using TSC’s planar DMOS technology.
The high breakdown voltage of the TSMxN100CP family allows use in poly-phase universal AC input voltage applications.
The RoHS compliant and Halogen free TO-252 (DPAK) is a thermally efficient and reliable package for space constrained power switching applications.
App…
![[Translate to English:] LED Treiber ICs Konstantstrom Controller](/fileadmin/_processed_/6/1/csm_led-driver-current-control-ts19751_72525ea251.jpg "[Translate to English:]")
| Optoelectronics, Active Components, BECK Elektronik
LED Lighting Driver ICs
A very efficient constant current controller IC for low cost non-dimmable LED lighting applications: TS19706CS.
The TS19706CS is configurable for either isolated primary side Flyback regulation or non-isolated buck-boost current regulation topologies.
Integrated 630 V Power MOSFET and active power factor correction in Flyback mode reduces the external components required and BOM for…
| Active Components, BECK Elektronik
BYG2x Avalanche Rectifiers for Automotive
TSC has recently added BYG21M (1.5A, 1000V, Fast Recovery) to its portfolio of avalanche surface mount rectifiers.
All BYG2x devices come in a halogen-free SMA package with AEC-Q qualified versions available for automotive applications.
Applications: free-wheeling, clamping, snubber, demagnetization in power supplies and other power switching application.
Features:
- Glass passivated junction…
